| Dimensions & Weight |
| Dimensions (W x D x H) | 413mm x 270mm x 14~40.5mm |
| Weight | 2.99Kg (including ODD and 48.84WH battery) |
| Chipset |
| Chipset | Intel® HM65 Express Chipset |
| Processor Support | 2nd Gen Intel® Core™ CPUs |
| Memory |
| Memory Type | Supports DDR-III 1333Mhz |
| Number of Modules | 2 x 1GB/2GB/4GB Modules |
| Maximum Supported Memory | 8GB |
| Hard Drive Capacity |
| Hard Drive Type | 1 x 9.5mm, 2.5” S-ATA HDD support |
| Display & Graphics |
| Graphics | Choice of graphics cards - refer to configurator. |
| Screen Size | 17.3 inch Widescreen |
| Native/Maximum Resolution | 1600 x 900 |
| Backlight | LED |
| Audio |
| Chipset | Intel High Definition Audio |
| Channels | 2 channel HD Audio |
| Connections | Microphone-in and headphone-out |
| Speakers | Built in two speakers |
| Integrated Microphone | Yes |
| Communications |
| LAN | Gigabit LAN |
| Wireless Support | Wireless LAN 802.11B/G/N Half Mini Card module |
| Bluetooth Support | Bluetooth V3.0 module support |
| Webcam | 1.3MP Webcam |
| Firewire (IEEE 1394) | N/A |
| Expansion Slots |
| PCI Express Card | N/A |
| TV Tuner | N/A |
| Keyboard & Mouse |
| Keys | Full size isolated keyboard with numeric pad |
| Language Support | Multi-Language support |
| Pointing Device | Touchpad Mouse | Built in touch pad with multi-gesture and scrolling function |
| Memory Card Reader |
| Memory Card Reader | 9-in-1 Card Reader |
| Webcam |
| Webcam | 1.3MP Webcam |
| Ports |
| HDMI Ports | 1 |
| USB | 3 x USB Ports including at least 1 x USB 3.0 Port |
| USB/e-SATA | 1 x e-SATA with GT 520M Only |
| Display | 1 x 15 pin VGA OUT port |
| Microphone-IN | 1 |
| Headphone-OUT | 1 |
| DC-in | 1 |
| LAN | 1 x RJ-45 jack |
| Kensington Lock | Yes |
| Battery & Power Lead |
| Battery Type | 6 cells Smart Lithium-Ion battery pack, 48.84WH |
| Typical Battery Life | Typical 4 Hour battery life under UMA mode |
| Power Lead & AC Adpater | 1 x Power Lead included with AC Adapter |
| Security |
| Fingerprint Scanner | N/A |
| Kensington Lock | Yes |
